HPE 361T

HPE 361T - netwerkadapter - PCIe 2.0 x4 - Gigabit Ethernet x 2

The HP 361T offers two high-performing 1GbE PCIe Gen 2.1 connections in a low cost, low power, halogen-free design. Based on the new fully integrated (bridgeless) Intel Ethernet I350 Controller, it introduces new levels of performance and power management technologies for HP ProLiant Gen8 DL/ML/SL servers and select G7 servers. It can be used with a full height or low profile bracket, and can operate at three different data rates (10/100/1000 Mbps). The HP 361T is positioned as the follow-on to the HP NC360T.

SPECIALS

HP ENTERPRISE

Leverancier	Categorie	Voorraad
TD SYNNEX	Nieuw	0
Copaco	Nieuw	0

Fabrikantcode

652497-B21

Dit product kan op dit moment niet besteld worden

Mail ons

Afmetingen & gewicht
Diepte	13.5 cm
Hoogte	6.4 cm
Algemeen
Type apparaat	Netwerkadapter
Ontworpen voor	HPE Apollo 4200 Gen10 ¦ HPE Nimble Storage dHCI Large Solution with HPE ProLiant DL380 Gen10, Medium Solution with HPE ProLiant DL360 Gen10, Small Solution with HPE ProLiant DL360 Gen10 ¦ HPE ProLiant DL180 Gen10, DL180 Gen10 Entry, DL180 Gen10 SMB, DL20 Gen10, DL20 Gen10 Entry, DL20 Gen10 Performance, DL20 Gen10 solution, DL20 Gen9 Solution, DL325 Gen10 Base, DL325 Gen10 Solution, DL360 Gen10, DL360 Gen10 All Flash Server for Weka, DL360 Gen10 Base, DL360 Gen10 Compute Server for Cohesity DataPlatform, DL360 Gen10 Entry, DL360 Gen10 High Performance, DL360 Gen10 Low, DL360 Gen10 Network Choice, DL360 Gen10 Performance, DL360 Gen10 Performance for Cohesity DataPlatform, DL360 Gen10 SMB, DL360 Gen10 SMB Network Choice, DL360 Gen10 Solution, DL380 Gen10, DL380 Gen10 All Flash Server for Datera, DL380 Gen10 Base, DL380 Gen10 Entry, DL380 Gen10 Entry SMB, DL380 Gen10 for Cohesity DataPlatform, DL380 Gen10 for SAP HANA Compute Block, DL380 Gen10 High Performance, DL380 Gen10 Hybrid Serve...
Luchtvochtigheidsgraad bij gebruik	10 - 95% (niet condenserend)
Max. gebruikstemperatuur	55 °C
Min. gebruikstemperatuur	0 °C
Hoogte	6.4 cm
Diepte	13.5 cm
Benodigd besturingssysteem	SUSE Linux Enterprise Server, Microsoft Windows Server 2008, Microsoft Windows HPC Server 2008, Oracle Solaris 10, Red Hat Enterprise Linux 6.1, VMware ESX 4.1, VMware ESXi 4.1, VMware ESXi 5, Red Hat Enterprise Linux 5.7, Citrix XenServer 6.0
Conformiteitsnormen	FCC Klasse B-gecertifieerd, UL, VCCI Class B ITE, CISPR 22 Class B, DOC-B, EN 60950, UL 1950, VCCI-II, WHQL, EN55022 Class B, ICES-003 Class B, MIC Class B, WEEE, RoHS, BSMI Class A
Meegeleverde accessoires	Platte steun
Uitwisselbare slots	1 x PCI Express 2.0 x4 - laag profiel
Interfaces	2 x 1000Base-T - RJ-45
Processor	1 x Intel I350
Voorzieningen	Automatische onderhandeling, WOL, NFT, Jumbo Frames ondersteuning, PXE ondersteuning, LSO, Energy Efficient Ethernet
Statuslampjes	Transmissiesnelheid van poort, link/activiteit
Protocol voor beheer op afstand	SNMP
Gegevensoverdrachtsnelheid	1 Gbps
Protocol voor gegevenskoppeling	Ethernet, Fast Ethernet, Gigabit Ethernet
Bekabelingstype	Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T
Connectiviteit	Met bekabeling
Poorten	Gigabit Ethernet x 2
PCI specificatierevisie	PCIe 2.0
Interface (Bus) Type	PCI Express 2.0 x4
Model	Insteekkaart - laag profiel
Diversen
Conformiteitsnormen	FCC Klasse B-gecertifieerd, UL, VCCI Class B ITE, CISPR 22 Class B, DOC-B, EN 60950, UL 1950, VCCI-II, WHQL, EN55022 Class B, ICES-003 Class B, MIC Class B, WEEE, RoHS, BSMI Class A
Meegeleverde accessoires	Platte steun
Informatie over Compatibiliteit
Ontworpen voor	HPE Apollo 4200 Gen10 ¦ HPE Nimble Storage dHCI Large Solution with HPE ProLiant DL380 Gen10, Medium Solution with HPE ProLiant DL360 Gen10, Small Solution with HPE ProLiant DL360 Gen10 ¦ HPE ProLiant DL180 Gen10, DL180 Gen10 Entry, DL180 Gen10 SMB, DL20 Gen10, DL20 Gen10 Entry, DL20 Gen10 Performance, DL20 Gen10 solution, DL20 Gen9 Solution, DL325 Gen10 Base, DL325 Gen10 Solution, DL360 Gen10, DL360 Gen10 All Flash Server for Weka, DL360 Gen10 Base, DL360 Gen10 Compute Server for Cohesity DataPlatform, DL360 Gen10 Entry, DL360 Gen10 High Performance, DL360 Gen10 Low, DL360 Gen10 Network Choice, DL360 Gen10 Performance, DL360 Gen10 Performance for Cohesity DataPlatform, DL360 Gen10 SMB, DL360 Gen10 SMB Network Choice, DL360 Gen10 Solution, DL380 Gen10, DL380 Gen10 All Flash Server for Datera, DL380 Gen10 Base, DL380 Gen10 Entry, DL380 Gen10 Entry SMB, DL380 Gen10 for Cohesity DataPlatform, DL380 Gen10 for SAP HANA Compute Block, DL380 Gen10 High Performance, DL380 Gen10 Hybrid Serve...
Netwerkgebruik
Conformiteitsnormen	IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1as, IEEE 802.3az
Voorzieningen	Automatische onderhandeling, WOL, NFT, Jumbo Frames ondersteuning, PXE ondersteuning, LSO, Energy Efficient Ethernet
Statuslampjes	Transmissiesnelheid van poort, link/activiteit
Protocol voor beheer op afstand	SNMP
Gegevensoverdrachtsnelheid	1 Gbps
Protocol voor gegevenskoppeling	Ethernet, Fast Ethernet, Gigabit Ethernet
Bekabelingstype	Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T
Connectiviteit	Met bekabeling
Poorten	Gigabit Ethernet x 2
Omgevingsparameters
Luchtvochtigheidsgraad bij gebruik	10 - 95% (niet condenserend)
Max. gebruikstemperatuur	55 °C
Min. gebruikstemperatuur	0 °C
Processor / Geheugen
Processor	1 x Intel I350
Software / Systeemvereisten
Benodigd besturingssysteem	SUSE Linux Enterprise Server, Microsoft Windows Server 2008, Microsoft Windows HPC Server 2008, Oracle Solaris 10, Red Hat Enterprise Linux 6.1, VMware ESX 4.1, VMware ESXi 4.1, VMware ESXi 5, Red Hat Enterprise Linux 5.7, Citrix XenServer 6.0
Uitbreiding / Aansluiting
Uitwisselbare slots	1 x PCI Express 2.0 x4 - laag profiel
Interfaces	2 x 1000Base-T - RJ-45
Informatie over Compatibiliteit
Ontworpen voor	HPE Apollo 4200 Gen10 ¦ HPE Nimble Storage dHCI Large Solution with HPE ProLiant DL380 Gen10, Medium Solution with HPE ProLiant DL360 Gen10, Small Solution with HPE ProLiant DL360 Gen10 ¦ HPE ProLiant DL180 Gen10, DL180 Gen10 Entry, DL180 Gen10 SMB, DL20 Gen10, DL20 Gen10 Entry, DL20 Gen10 Performance, DL20 Gen10 solution, DL20 Gen9 Solution, DL325 Gen10 Base, DL325 Gen10 Solution, DL360 Gen10, DL360 Gen10 All Flash Server for Weka, DL360 Gen10 Base, DL360 Gen10 Compute Server for Cohesity DataPlatform, DL360 Gen10 Entry, DL360 Gen10 High Performance, DL360 Gen10 Low, DL360 Gen10 Network Choice, DL360 Gen10 Performance, DL360 Gen10 Performance for Cohesity DataPlatform, DL360 Gen10 SMB, DL360 Gen10 SMB Network Choice, DL360 Gen10 Solution, DL380 Gen10, DL380 Gen10 All Flash Server for Datera, DL380 Gen10 Base, DL380 Gen10 Entry, DL380 Gen10 Entry SMB, DL380 Gen10 for Cohesity DataPlatform, DL380 Gen10 for SAP HANA Compute Block, DL380 Gen10 High Performance, DL380 Gen10 Hybrid Server for Datera, DL380 Gen10 Network Choice, DL380 Gen10 Network Choice for CTERA, DL380 Gen10 NVMe All Flash Server for Datera, DL380 Gen10 Performance, DL380 Gen10 Server for CTERA, DL380 Gen10 SMB, DL380 Gen10 SMB Networking Choice, DL380 Gen10 Solution, DL388 Gen10 Network Choice, DL388p Gen8 Base, DL560 Gen10, DL560 Gen10 Base, DL560 Gen10 Entry, DL560 Gen10 for SAP HANA Compute Block, DL560 Gen10 Performance, DL580 Gen10, DL580 Gen10 Base, DL580 Gen10 Entry, DL580 Gen10 Performance, ML110 Gen10, ML110 Gen10 Entry, ML110 Gen10 Performance, ML110 Gen10 Solution, ML30 Gen10, ML30 Gen10 Entry, ML30 Gen10 Performance, ML30 Gen10 Solution, ML30 Gen9 Entry, ML30 Gen9 Solution, ML350 Gen10, ML350 Gen10 Base, ML350 Gen10 Entry, ML350 Gen10 High Performance, ML350 Gen10 Performance, ML350 Gen10 SMB, ML350 Gen10 Solution, ML350 Gen10 Special Server, ML350 Gen10 Sub-Entry, XL230k Gen10 Compute Tray, XL450 Gen10 ¦ HPE SimpliVity 380 Gen9 Node
