HPE 530T

HPE 530T - netwerkadapter - PCIe 2.0 x8 - 10Gb Ethernet

De HPE Ethernet 10Gb 2-poorts 530T Adapter is een dual-poorts 10GBASE-T adapter, met de 57810S 10 GbE oplossing van QLogic in een PCIe 2.0 compliant vormfactor ontworpen voor HPE ProLiant servers. De HPE 530T Adapter levert volledige line-rate prestaties over alle poorten met een laag stroomverbruik en maakt gebruik van CAT 6A UTP-bekabeling met afstanden tot 100 meter.

SPECIALS

HP ENTERPRISE

Leverancier	Categorie	Voorraad
TD SYNNEX	Nieuw	0

Fabrikantcode

656596-B21

Dit product kan op dit moment niet besteld worden

Mail ons

Algemeen
Type apparaat	Netwerkadapter
Model	Insteekkaart
Interface (Bus) Type	PCI Express 2.0 x8
Poorten	10Gb Ethernet
Connectiviteit	Met bekabeling
Bekabelingstype	Ethernet 1000Base-T, Ethernet 10GBase-T
Protocol voor gegevenskoppeling	Gigabit Ethernet, 10 Gigabit Ethernet
Voorzieningen	TCP/IP ontlasting, Jumbo Frames ondersteuning, teaming support, PXE ondersteuning, RSS, gemerkte VLAN, MSI-X
Conformiteitsnormen	UL, BSMI, BSMI CNS 13438 Class A, EN55024, EN55022 Klasse A, ICES-003 Klasse A, WEEE, FCC Part 15 A, EN 61000-3-2:2006, EN 61000-3-3:2008
Processor	Broadcom BCM57810S
RAM	256 MB
Interfaces	1 x 10GBase-T - RJ-45
Uitwisselbare slots	1 x PCI Express 2.0 x8
Benodigd besturingssysteem	SunSoft Solaris 10, Microsoft Windows HPC Server 2008 SP2, Microsoft Windows Small Business Server 2011 Essentials, Microsoft Windows MultiPoint Server 2011, Microsoft Windows Small Business Server 2011, Microsoft Windows Server 2008 (32-/64-bits) SP2, Red Hat Enterprise Linux 6.1, Red Hat Enterprise Linux 6.2, Red Hat Enterprise Linux 5.7, SuSE Linux Enterprise Server 10 SP4, Citrix XenServer 6.0, SuSE Linux Enterprise Server 11 SP2, Microsoft Windows Server 2012, Red Hat Enterprise Linux 5.8, Microsoft Windows Server 2008 R2 SP1 (32/64 bits), Microsoft Windows HPC Server 2008 R2 SP1, Red Hat Enterprise Linux 5.9, Red Hat Enterprise Linux 6.3, SunSoft Solaris 11, Citrix XenServer 6.1
Min. gebruikstemperatuur	0 °C
Max. gebruikstemperatuur	55 °C
Luchtvochtigheidsgraad bij gebruik	5 - 95% (niet-condenserend)
Ontworpen voor	HPE Apollo 4200 Gen10, 4200 Gen10 for HPE Ezmeral Container Platform, 4200 Gen10 for HPE Ezmeral Tracking, 4200 Gen9 for Google ¦ HPE Nimble Storage dHCI Large Solution with HPE ProLiant DL380 Gen10, Medium Solution with HPE ProLiant DL360 Gen10, Small Solution with HPE ProLiant DL360 Gen10 ¦ HPE ProLiant DL120 Gen10, DL180 Gen10, DL180 Gen10 Entry, DL180 Gen10 SMB, DL20 Gen10, DL20 Gen10 Entry, DL20 Gen10 Performance, DL20 Gen10 solution, DL20 Gen9 Solution, DL325 Gen10 Base, DL325 Gen10 Solution, DL360 Gen10 All Flash Server for Weka, DL360 Gen10 Compute Server for Cohesity DataPlatform, DL360 Gen10 Low, DL360 Gen10 Network Choice, DL360 Gen10 Performance for Cohesity DataPlatform, DL360 Gen10 SMB, DL360 Gen10 SMB Network Choice, DL360 Gen10 Solution, DL380 Gen10 All Flash Server for Datera, DL380 Gen10 Entry SMB, DL380 Gen10 for Cohesity DataPlatform, DL380 Gen10 for SAP HANA Compute Block, DL380 Gen10 Hybrid Server for Datera, DL380 Gen10 Network Choice, DL380 Gen10 Network Choi...
Diversen
Conformiteitsnormen	UL, BSMI, BSMI CNS 13438 Class A, EN55024, EN55022 Klasse A, ICES-003 Klasse A, WEEE, FCC Part 15 A, EN 61000-3-2:2006, EN 61000-3-3:2008
Informatie over Compatibiliteit
Ontworpen voor	HPE Apollo 4200 Gen10, 4200 Gen10 for HPE Ezmeral Container Platform, 4200 Gen10 for HPE Ezmeral Tracking, 4200 Gen9 for Google ¦ HPE Nimble Storage dHCI Large Solution with HPE ProLiant DL380 Gen10, Medium Solution with HPE ProLiant DL360 Gen10, Small Solution with HPE ProLiant DL360 Gen10 ¦ HPE ProLiant DL120 Gen10, DL180 Gen10, DL180 Gen10 Entry, DL180 Gen10 SMB, DL20 Gen10, DL20 Gen10 Entry, DL20 Gen10 Performance, DL20 Gen10 solution, DL20 Gen9 Solution, DL325 Gen10 Base, DL325 Gen10 Solution, DL360 Gen10 All Flash Server for Weka, DL360 Gen10 Compute Server for Cohesity DataPlatform, DL360 Gen10 Low, DL360 Gen10 Network Choice, DL360 Gen10 Performance for Cohesity DataPlatform, DL360 Gen10 SMB, DL360 Gen10 SMB Network Choice, DL360 Gen10 Solution, DL380 Gen10 All Flash Server for Datera, DL380 Gen10 Entry SMB, DL380 Gen10 for Cohesity DataPlatform, DL380 Gen10 for SAP HANA Compute Block, DL380 Gen10 Hybrid Server for Datera, DL380 Gen10 Network Choice, DL380 Gen10 Network Choi...
Netwerkgebruik
Poorten	10Gb Ethernet
Connectiviteit	Met bekabeling
Bekabelingstype	Ethernet 1000Base-T, Ethernet 10GBase-T
Protocol voor gegevenskoppeling	Gigabit Ethernet, 10 Gigabit Ethernet
Voorzieningen	TCP/IP ontlasting, Jumbo Frames ondersteuning, teaming support, PXE ondersteuning, RSS, gemerkte VLAN, MSI-X
Conformiteitsnormen	IEEE 802.3, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1AX, IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 802.1Qau, IEEE 802.1Qbg, IEEE 802.2x
Omgevingsparameters
Min. gebruikstemperatuur	0 °C
Max. gebruikstemperatuur	55 °C
Luchtvochtigheidsgraad bij gebruik	5 - 95% (niet-condenserend)
Processor / Geheugen
Processor	Broadcom BCM57810S
RAM	256 MB
Software / Systeemvereisten
Benodigd besturingssysteem	SunSoft Solaris 10, Microsoft Windows HPC Server 2008 SP2, Microsoft Windows Small Business Server 2011 Essentials, Microsoft Windows MultiPoint Server 2011, Microsoft Windows Small Business Server 2011, Microsoft Windows Server 2008 (32-/64-bits) SP2, Red Hat Enterprise Linux 6.1, Red Hat Enterprise Linux 6.2, Red Hat Enterprise Linux 5.7, SuSE Linux Enterprise Server 10 SP4, Citrix XenServer 6.0, SuSE Linux Enterprise Server 11 SP2, Microsoft Windows Server 2012, Red Hat Enterprise Linux 5.8, Microsoft Windows Server 2008 R2 SP1 (32/64 bits), Microsoft Windows HPC Server 2008 R2 SP1, Red Hat Enterprise Linux 5.9, Red Hat Enterprise Linux 6.3, SunSoft Solaris 11, Citrix XenServer 6.1
Uitbreiding / Aansluiting
Interfaces	1 x 10GBase-T - RJ-45
Uitwisselbare slots	1 x PCI Express 2.0 x8
Informatie over Compatibiliteit
Ontworpen voor	HPE Apollo 4200 Gen10, 4200 Gen10 for HPE Ezmeral Container Platform, 4200 Gen10 for HPE Ezmeral Tracking, 4200 Gen9 for Google ¦ HPE Nimble Storage dHCI Large Solution with HPE ProLiant DL380 Gen10, Medium Solution with HPE ProLiant DL360 Gen10, Small Solution with HPE ProLiant DL360 Gen10 ¦ HPE ProLiant DL120 Gen10, DL180 Gen10, DL180 Gen10 Entry, DL180 Gen10 SMB, DL20 Gen10, DL20 Gen10 Entry, DL20 Gen10 Performance, DL20 Gen10 solution, DL20 Gen9 Solution, DL325 Gen10 Base, DL325 Gen10 Solution, DL360 Gen10 All Flash Server for Weka, DL360 Gen10 Compute Server for Cohesity DataPlatform, DL360 Gen10 Low, DL360 Gen10 Network Choice, DL360 Gen10 Performance for Cohesity DataPlatform, DL360 Gen10 SMB, DL360 Gen10 SMB Network Choice, DL360 Gen10 Solution, DL380 Gen10 All Flash Server for Datera, DL380 Gen10 Entry SMB, DL380 Gen10 for Cohesity DataPlatform, DL380 Gen10 for SAP HANA Compute Block, DL380 Gen10 Hybrid Server for Datera, DL380 Gen10 Network Choice, DL380 Gen10 Network Choice for CTERA, DL380 Gen10 NVMe All Flash Server for Datera, DL380 Gen10 Server for CTERA, DL380 Gen10 SMB, DL380 Gen10 SMB Networking Choice, DL380 Gen10 Solution, DL388 Gen10 Network Choice, DL388p Gen8 Base, DL560 Gen10 for SAP HANA Compute Block, DL580 Gen10 Base, DL580 Gen10 Entry, DL580 Gen10 Performance, ML110 Gen10 Solution, ML30 Gen10, ML30 Gen10 Entry, ML30 Gen10 Performance, ML30 Gen10 Solution, ML30 Gen9 Entry, ML30 Gen9 Solution, ML350 Gen10 High Performance, ML350 Gen10 SMB, ML350 Gen10 Solution, ML350 Gen10 Special Server, XL170r Gen10 24TB Server for Cohesity DataPlatform, XL170r Gen10 36TB Add-on Server for Cohesity DataPlatform, XL170r Gen10 Server for BlueData EPIC, XL190r Gen10 for HPE Ezmeral Container Platform, XL450 Gen10 ¦ HPE SimpliVity 325 Gen10 Node, 380 Gen10 G Node, 380 Gen10 H Node, 380 Gen10 Network Choice G Node, 380 Gen10 Network Choice H Node, 380 Gen10 Node ¦ HPE StoreEasy 1660 Expanded Storage
