HPE 640SFP28

HPE 640SFP28 - netwerkadapter - PCIe 3.0 x8 / PCIe 3.0 x4 - 25 Gigabit Ethernet x 2

The HPE Ethernet 10/25 Gb 2-port 640SFP28 adapter for ProLiant Gen9 rack servers are designed to optimize Cloud efficiency, and improve performance and security of applications – especially where I/O, block storage and database performance are critical and the need for maximum VM density and up-scalability are greatest. The HPE Ethernet 640SFP28 can provide up to 100 Gbps of converged bi-directional Ethernet bandwidth, helping to alleviate network bottlenecks. This adapter can also run at 10 Gb for customers who have not changed the infrastructure/switches to 25 Gb yet.

SPECIALS

HP ENTERPRISE

Leverancier	Categorie	Voorraad
TD SYNNEX	Nieuw	0
Ingram Micro	Nieuw	1
Copaco	Nieuw	0

Fabrikantcode

817753-B21

Bestel

Algemeen
Type apparaat	Netwerkadapter
Ontworpen voor	HPE Apollo 20 2U Node, 4200 Gen10, 4200 Gen10 336TB Archive Node with 25Gb NIC for Qumulo, 4200 Gen10 for HPE Ezmeral Container Platform, 4200 Gen10 for HPE Ezmeral Tracking, 4200 Gen10 Qumulo Archive Node, 4200 Gen10 Qumulo Hybrid Node, 4200 Gen9 for Google ¦ HPE Edgeline e920, e920d ¦ HPE Nimble Storage dHCI Large Solution with HPE ProLiant DL380 Gen10, Medium Solution with HPE ProLiant DL360 Gen10, Small Solution with HPE ProLiant DL360 Gen10 ¦ HPE ProLiant DL180 Gen10 Entry, DL180 Gen10 SMB, DL325 Gen10 Base, DL325 Gen10 Solution, DL360 Gen10 All Flash Server for Weka, DL360 Gen10 Compute Server for Cohesity DataPlatform, DL360 Gen10 Low, DL360 Gen10 Network Choice, DL360 Gen10 Performance for Cohesity DataPlatform, DL360 Gen10 SMB, DL360 Gen10 SMB Network Choice, DL360 Gen10 Solution, DL360 Gen9 High Performance, DL380 Gen10 All Flash Server for Datera, DL380 Gen10 Entry SMB, DL380 Gen10 for Cohesity DataPlatform, DL380 Gen10 for SAP HANA Compute Block, DL380 Gen10 Hybrid Serve...
Luchtvochtigheidsgraad bij gebruik	5 - 95% (niet-condenserend)
Max. gebruikstemperatuur	60 °C
Min. gebruikstemperatuur	5 °C
Service & Support	Beperkte garantie - 1 jaar
Benodigd besturingssysteem	SuSE Linux Enterprise Server 11, Microsoft Windows Server 2012, Oracle Solaris 11.1, Microsoft Windows Server 2012 R2, VMware ESXi 5.5, Ubuntu 14.04, Red Hat Enterprise Linux 7, Red Hat Enterprise Linux 6.6, Red Hat Enterprise Linux 7.1, Citrix XenServer 6.5, SuSE Linux Enterprise Server 12, Red Hat Enterprise Linux 6.7, Red Hat Enterprise Linux 7.2, VMware ESXi 6.0
Energieverbruik tijdens gebruik	9.7 Watt
Conformiteitsnormen	FCC klasse A-gecertificeerd, CISPR 22 Klasse A, ICES-003, EN55024, EN 60950-1, RoHS, ACA, cTUVus, BSMI Class A, VCCI Class A, EN 55022 Class A
Interfaces	2 x 25Gb Ethernet - SFP28
Processor	1 x Mellanox Technologies Mellanox ConnectX-4 Lx
Voorzieningen	VLAN-ondersteuning, IPv6-ondersteuning, volledige duplex modus, TCP/IP ontlasting, QoS, Jumbo Frames ondersteuning, IPv4-ondersteuning, PXE ondersteuning, LACP ondersteuning, LLDP ondersteuning, LSO, RSS, UEFI-ondersteuning, TSO, Qos-tagging, MSI-X, UDP/IP offloading, TCP/IP checksum offload, RoCE, VXLAN, NVGRE, RoCE v2
Statuslampjes	Link/activiteit
Protocol voor beheer op afstand	SNMP
Capaciteit	Jumbo frameafmetingen: max. 9,6 KB
Prestaties	Bidrectionele verwerkingscapaciteit: 100 Gbps ¦ Bandwijdte per poort: 50 Gbps
Gegevensoverdrachtsnelheid	25 Gbps
Protocol voor gegevenskoppeling	10 Gigabit Ethernet, 25 Gigabit Ethernet
Connectiviteit	Met bekabeling
Poorten	25 Gigabit Ethernet x 2
PCI specificatierevisie	PCIe 3.0
Interface (Bus) Type	PCI Express 3.0 x8 / PCI Express 3.0 x4
Model	Insteekkaart - laag profiel
Diversen
Conformiteitsnormen	FCC klasse A-gecertificeerd, CISPR 22 Klasse A, ICES-003, EN55024, EN 60950-1, RoHS, ACA, cTUVus, BSMI Class A, VCCI Class A, EN 55022 Class A
Garantie van de fabrikant
Service & Support	Beperkte garantie - 1 jaar
Informatie over Compatibiliteit
Ontworpen voor	HPE Apollo 20 2U Node, 4200 Gen10, 4200 Gen10 336TB Archive Node with 25Gb NIC for Qumulo, 4200 Gen10 for HPE Ezmeral Container Platform, 4200 Gen10 for HPE Ezmeral Tracking, 4200 Gen10 Qumulo Archive Node, 4200 Gen10 Qumulo Hybrid Node, 4200 Gen9 for Google ¦ HPE Edgeline e920, e920d ¦ HPE Nimble Storage dHCI Large Solution with HPE ProLiant DL380 Gen10, Medium Solution with HPE ProLiant DL360 Gen10, Small Solution with HPE ProLiant DL360 Gen10 ¦ HPE ProLiant DL180 Gen10 Entry, DL180 Gen10 SMB, DL325 Gen10 Base, DL325 Gen10 Solution, DL360 Gen10 All Flash Server for Weka, DL360 Gen10 Compute Server for Cohesity DataPlatform, DL360 Gen10 Low, DL360 Gen10 Network Choice, DL360 Gen10 Performance for Cohesity DataPlatform, DL360 Gen10 SMB, DL360 Gen10 SMB Network Choice, DL360 Gen10 Solution, DL360 Gen9 High Performance, DL380 Gen10 All Flash Server for Datera, DL380 Gen10 Entry SMB, DL380 Gen10 for Cohesity DataPlatform, DL380 Gen10 for SAP HANA Compute Block, DL380 Gen10 Hybrid Serve...
Netwerkgebruik
Conformiteitsnormen	IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.1ab (LLDP), IEEE 802.3az, IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 802.1Qau, IEEE 802.1Qbg, IEEE 1588v2
Voorzieningen	VLAN-ondersteuning, IPv6-ondersteuning, volledige duplex modus, TCP/IP ontlasting, QoS, Jumbo Frames ondersteuning, IPv4-ondersteuning, PXE ondersteuning, LACP ondersteuning, LLDP ondersteuning, LSO, RSS, UEFI-ondersteuning, TSO, Qos-tagging, MSI-X, UDP/IP offloading, TCP/IP checksum offload, RoCE, VXLAN, NVGRE, RoCE v2
Statuslampjes	Link/activiteit
Protocol voor beheer op afstand	SNMP
Capaciteit	Jumbo frameafmetingen: max. 9,6 KB
Prestaties	Bidrectionele verwerkingscapaciteit: 100 Gbps ¦ Bandwijdte per poort: 50 Gbps
Gegevensoverdrachtsnelheid	25 Gbps
Protocol voor gegevenskoppeling	10 Gigabit Ethernet, 25 Gigabit Ethernet
Connectiviteit	Met bekabeling
Poorten	25 Gigabit Ethernet x 2
Omgevingsparameters
Luchtvochtigheidsgraad bij gebruik	5 - 95% (niet-condenserend)
Max. gebruikstemperatuur	60 °C
Min. gebruikstemperatuur	5 °C
Processor / Geheugen
Processor	1 x Mellanox Technologies Mellanox ConnectX-4 Lx
Software / Systeemvereisten
Benodigd besturingssysteem	SuSE Linux Enterprise Server 11, Microsoft Windows Server 2012, Oracle Solaris 11.1, Microsoft Windows Server 2012 R2, VMware ESXi 5.5, Ubuntu 14.04, Red Hat Enterprise Linux 7, Red Hat Enterprise Linux 6.6, Red Hat Enterprise Linux 7.1, Citrix XenServer 6.5, SuSE Linux Enterprise Server 12, Red Hat Enterprise Linux 6.7, Red Hat Enterprise Linux 7.2, VMware ESXi 6.0
Stroom
Energieverbruik tijdens gebruik	9.7 Watt
Uitbreiding / Aansluiting
Interfaces	2 x 25Gb Ethernet - SFP28
Informatie over Compatibiliteit
Ontworpen voor	HPE Apollo 20 2U Node, 4200 Gen10, 4200 Gen10 336TB Archive Node with 25Gb NIC for Qumulo, 4200 Gen10 for HPE Ezmeral Container Platform, 4200 Gen10 for HPE Ezmeral Tracking, 4200 Gen10 Qumulo Archive Node, 4200 Gen10 Qumulo Hybrid Node, 4200 Gen9 for Google ¦ HPE Edgeline e920, e920d ¦ HPE Nimble Storage dHCI Large Solution with HPE ProLiant DL380 Gen10, Medium Solution with HPE ProLiant DL360 Gen10, Small Solution with HPE ProLiant DL360 Gen10 ¦ HPE ProLiant DL180 Gen10 Entry, DL180 Gen10 SMB, DL325 Gen10 Base, DL325 Gen10 Solution, DL360 Gen10 All Flash Server for Weka, DL360 Gen10 Compute Server for Cohesity DataPlatform, DL360 Gen10 Low, DL360 Gen10 Network Choice, DL360 Gen10 Performance for Cohesity DataPlatform, DL360 Gen10 SMB, DL360 Gen10 SMB Network Choice, DL360 Gen10 Solution, DL360 Gen9 High Performance, DL380 Gen10 All Flash Server for Datera, DL380 Gen10 Entry SMB, DL380 Gen10 for Cohesity DataPlatform, DL380 Gen10 for SAP HANA Compute Block, DL380 Gen10 Hybrid Server for Datera, DL380 Gen10 Network Choice, DL380 Gen10 Network Choice for CTERA, DL380 Gen10 NVMe All Flash Server for Datera, DL380 Gen10 Server for CTERA, DL380 Gen10 SMB, DL380 Gen10 SMB Networking Choice, DL380 Gen10 Solution, DL388 Gen10 Network Choice, DL560 Gen10 for SAP HANA Compute Block, DL580 Gen9 SAP HANA Scale-out Base Configuration, DL580 Gen9 SAP HANA Scale-up Base Configuration, DX380 Gen10, DX560 Gen10, ML350 Gen10 High Performance, ML350 Gen10 SMB, ML350 Gen10 Solution, ML350 Gen10 Special Server, XL170r Gen10 24TB Server for Cohesity DataPlatform, XL170r Gen10 36TB Add-on Server for Cohesity DataPlatform, XL170r Gen10 Server for BlueData EPIC, XL190r Gen10 for HPE Ezmeral Container Platform, XL270d Gen10 for HPE Ezmeral Container Platform, XL450 Gen10 ¦ HPE SimpliVity 325 Gen10 Node, 380 Gen10 G Node, 380 Gen10 H Node, 380 Gen10 Network Choice G Node, 380 Gen10 Network Choice H Node ¦ HPE StoreEasy 1660 Expanded Storage
